B&M Traveler Automatic Transmission for 4 wheel drive - GM TH350

1965-1991 Chevrolet Small Block and Big Block 4-Wheel Drive, Automatic Shift Valve Body

PART# 103005

Be the first to write a review
$1,661.95   Suggested Retail
$1,494.95   Your Price
In Stock

To place an order, please call 1-866-464-6553

To place an order, please call 1-866-464-6553

Add to Wish List

Starting at $132 a month with Learn More

Overview

The B&M Traveler series TH350 transmission is designed for 4-Wheel Drive applications and bolts directly to all GM NP203 and NP205 transfer cases with a 27 spline input. The Traveler transmissions are built for light trucks, off-road and RV/towing applications and feature high performance friction plates, rebuilt pump, recalibrated forward pattern valve body for medium/firm shifts and are capable of handling up to 425hp. The Traveler series also includes increased oil flow, which aids in cooler operation under heavy duty use and towing. B&M strongly recommends protecting your investment by adding a B&M Hi-Tek SuperCooler and new flexplate with all new transmission installations. Note: Does not include torque convertor, speedometer gear or dipstick.

Features:

  • High Performance Friction Plates
  • Fits NP203 and NP205 Transfer Cases
  • Recalibrated Forward Pattern Valve Body
  • Built for Tough Off-Road and Towing Conditions

Specs

2WD/4WD4WD
Automotive Item GradeHigh Performance
Brake IncludedNo
BrandB&M
Built-In Transmission ShieldNo
California Proposition 65 Chemical NameBenzene
Chromium (hexavalent compounds)
Lead
California Proposition 65 RequiredYes
Case MaterialCast Aluminum
ColorBlack
Control TypeHydraulic
Converter Stall Speed (RPM)N/A
Cooler includedNo
Core Change ApplicableNo
Dipstick includedNo
Drive Type4WD
Emission Code5
Friction PlatesNew
Gear Ratio-First2.52
Gear Ratio-Second1.52
Gear Ratio-Third1.00
Horsepower Rating (HP)450
Manual Valve BodyNo
Part TypeOff Road
Product TypeAutomatic Transmission Assembly
Reverse Gear Ratio1.93
Reverse PatternNo
Tailshaft Length (In)N/A
Torque Converter IncludedNo
Torque Converter SeriesN/A
Torque Rating (Ft/Lbs)400
TransbrakeNo
Transmission ModelTH350
Transmission Pan FinishChrome
Transmission Pan MaterialSteel
Transmission Pan TypeStamped
Transmission SeriesTraveler
Transmission Speeds3
Transmission TypeTH350
Valve Body ConfigurationRecalibrated
Valve Body PatternForward
Valve Body TypeAutomatic
Part Number103005

Emissions

This part is legal for sale or use on Emissions Controlled Vehicles, Uncontrolled (Non-Emissions Controlled) Vehicles, and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations.
