Build Points
38
- Color: Gray
- Horsepower: 625
- Drivetrain: RWD
EDIT
EDIT
EDIT
EDIT
EDIT
EDIT
EDIT
EDIT
EDIT
EDIT
See More
Vehicle Overview
Engine: Rhyne Competition Engines.
436 C.I. Dyno @ 620 H.P., 590 FT LBS Torque
Dart aluminum block, raised cam, wide pan rails.
Callies 4340 - 4.00 stroke Magnum Plus crankshaft.
L.A. Kryptonite connecting rods 5.850 with CARR bolts.
J.E. Custom Pistons, Casidiam coated taper wall wristpins.
Comp Hyd roller cam & lifters, Manley .080 wall pushrods,
T&D shaft rockers 1.65 INT. 1.55 EXH w/spring oilers.
18° GM Bowtie heads from a NASCAR Craftsman Truck.
Del West titanium intake valves 2.150 head
Ferrea SS hollow stem exh valves, Bee Hive springs & retainers.
18° GM Bowtie intake, HVH carb spacer, FI Tech fuel injection.
ZEX nitrous kit w/ perimeter plate & custom bottle mount.
Earls engine oil cooler behind the grill. Be-Cool alum radiator.
Custom 3” exhaust w/ x-pipe & 50 series Flowmasters.
Transmission: Trans PRO.
Custom 700R4 Built to withstand 590 ft lbs of torque.
Coan 3000 stall “lock up” torque converter.
Custom lock up controller.
Aluminum crossmember, Earls trans cooler behind the grill.
Rear End: Custom Built.
Ford 9”, 3.90 gear, Detroit locker center, Winters alum case.
Strange Engineering custom 31 spline axles.
Strange chrome moly driveshaft with billet front yoke.
Brakes:
13" Wilwood Front disc with drilled & slotted rotors & 6-Piston calipers.
11 3/4" Wilwood Rear disc with drilled & slotted rotors & 4-Piston calipers.
Wheels & Tires:
American Racing aluminum wheels 17x8 front & rear.
Dunlop Sport 8000 tires 225/55-16 front, 255/50-16 rear.
Suspension:
Ebaich lowering springs, Bilstein shocks,
1 3/8” hollow front sway bar (F-body) & 1” rear sway bar.
Boxed rear lower arms, adjustable rear upper arms.
Tubular upper front A-arms, all polyurethane bushings.
Interior:
Custom Autometer Phantom gauges / Carbon fiber dash.
Custom R&R rocker switches, Momo steering wheel.
B&M Black Diamond ratchet shifter w/ nitrous control.
Exterior:
Harwood 4” cowl induction hood.
Custom headlights w/ Piaa bulbs & Clear headlight covers
