- Color: Black
- Horsepower: 500
- Drivetrain: RWD
I've had my four-eye since back in high school. Over the years she's had different engine combinations, transmissions and rear ends. Everything has been in the name of speed. In its current incarnation it packs a F2 Procharged, 383 SBF. Trick Flow Street Heat heads disperse the compressed air. Power rows through an ATI powerglide and out to the built 8.8 rear end. Finally after 30 plus years of owning my foxbody, she's finally fuel injected. Never thought I'd cross that threshold. I've been a blow-thru guy since way back in the day. Technology sure is great!
Wiring Diagram: Loose Wires04/20/2020
Here are the loose wires and where they go.
Wiring Diagram: Sensor Connections04/20/2020
This one is self-explanatory
Wiring Diagram: MSD Solid State Relay04/20/2020
Here is how I wired the solid state relay into Terminator X
Wiring Diagram: Water Pump, Electric Fan04/20/2020
Here is the electric fan and water pump wiring.
Wiring Diagram: Fuel System04/20/2020
Heres how I wired up the fuel pump and controller.
Bypass Fuel System04/19/2020
Here is the bypass fuel system install.
Terminator X: Setting up the Inputs and Outputs04/16/2020
How to setup the inputs and outputs on Terminator X or Sniper EFI.
Terminator X for Ford: MSD Pro 600 and Cam Sync04/16/2020
Here is the MSD Pro 600 and Cam Sync install.
Terminator X for Ford: Sensors and Relay Wiring04/16/2020
Here is my Terminator X for Ford install.
- Foxbody 5.0L Specific MPFI Main Harness - 92-97 4R70W Transmission Control Harness- Ford Spaced EV1 Injector Harness, 3.5" Touchscreen Included
Rolling down the nearest track!
